High Efficient Catalysts Air Stream Dryer FOR PHARM FOODSTUFF CHEMICAL INDUSTRY
| Place of Origin | CHINA |
|---|---|
| Brand Name | XSG |
| Certification | CE / UL / SGS / EAC / CR – TU |
| Model Number | YIBU |
| Minimum Order Quantity | 1 set |
| Price | Negotiation |
| Packaging Details | Woodencase |
| Delivery Time | 10weeks |
| Payment Terms | L/C, T/T |
| Supply Ability | 20 SETS PER MONTH |
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Metal Material | SUS316/SUS304/ CARBON STEEL ,ETC | Heating Source | Steam / Electrical / Natural Gas / Diesel / Etc |
|---|---|---|---|
| Temperature | 100-500℃ | Capacity | 200-8000kg/h |
| Water Evaporation | 10-2000kg/h | Power | Customized |
| Highlight | hot air dryer,rotating drum dryer,catalysts air stream dryer |
||
Product Description
SS304 SS316 XSG Series Catalysts Spin Flash Drying Machine( Air Stream Dryer ) foodstuff industry
spin flash drying machine Description
XSG series rotary flash drying machine is my factory in the introduction, absorption, on the basis of foreign advanced technology, successfully developed a new type of drying equipment. This advanced technology, reasonable design, compact structure, wide scope of application, large production capacity, products of good quality and high efficiency, energy saving, in a dry equipment, crushing, sieving one-time completed, eliminate the pollution of the environment, the whole machine performance reached the international advanced technology level.flash drying machine Principle
Hot air by the inlet pipe to the suitable spouted velocity from the bottom of the dryer into the mixing crushed drying chamber, the material produce strong shearing, blowing floating and rotating effect, so the material by centrifuge, shearing, collision, friction and particles, and to strengthen the heat transfer and mass transfer. At the bottom of the dryer is bigger than the wet particle mass under the action of stirrer were mechanical crushing, with low moisture content, granularity of smaller particles entrained by the rotating flow increase, rising further in the process of drying. Because of gas-solid two phase rotating flow, solid phase of inertia is greater than the gas phase and two phases of gas in the relative velocity is larger, strengthen two heat transfer and mass transfer, so the machine produce high strength.
Hot air by the inlet pipe to the suitable spouted velocity from the bottom of the dryer into the mixing crushed drying chamber, the material produce strong shearing, blowing floating and rotating effect, so the material by centrifuge, shearing, collision, friction and particles, and to strengthen the heat transfer and mass transfer. At the bottom of the dryer is bigger than the wet particle mass under the action of stirrer were mechanical crushing, with low moisture content, granularity of smaller particles entrained by the rotating flow increase, rising further in the process of drying. Because of gas-solid two phase rotating flow, solid phase of inertia is greater than the gas phase and two phases of gas in the relative velocity is larger, strengthen two heat transfer and mass transfer, so the machine produce high strength.
flash drying machine Features
Variety of feeding device for selection, continuous stable feeding, process won't produce bridge phenomenon in the middle.
"At the bottom of the dryer set special cooling device, avoids the production material in the bottom of drier deterioration phenomenon.
Second-ranking special pressure seal and bearing cooling device, effectively prolong the service life of transmission parts.
Low special air distributing device, reduce the resistance of the equipment, and provide the effective of air dryer.
There are rotation flow pieces and low drying chamber fitted with grading ring, adjustable fineness and raw material. (such as calcium carbonate water regulator to 0.1% or less)
Low compared with other drying method, which can effectively increase the material proportion.
Low dry indoor circumferential gas velocity is high, the material stay time is short, effective prevent deterioration phenomenon of wall material viscosity and heat sensitive material, to achieve efficient, fast, small equipment, mass production.
Variety of feeding device for selection, continuous stable feeding, process won't produce bridge phenomenon in the middle.
"At the bottom of the dryer set special cooling device, avoids the production material in the bottom of drier deterioration phenomenon.
Second-ranking special pressure seal and bearing cooling device, effectively prolong the service life of transmission parts.
Low special air distributing device, reduce the resistance of the equipment, and provide the effective of air dryer.
There are rotation flow pieces and low drying chamber fitted with grading ring, adjustable fineness and raw material. (such as calcium carbonate water regulator to 0.1% or less)
Low compared with other drying method, which can effectively increase the material proportion.
Low dry indoor circumferential gas velocity is high, the material stay time is short, effective prevent deterioration phenomenon of wall material viscosity and heat sensitive material, to achieve efficient, fast, small equipment, mass production.
flash drying machine Material
Low categories: inorganic borate, calcium carbonate, hydroxide, copper sulfate, ferric oxide, barium carbonate, antimony trioxide, all kinds of metallic hydroxide, all kinds of heavy metal salt, synthetic cryolite and so on.
Low organic matter: atrazine (pesticides), lauric acid, benzoic acid, benzoic acid, antiseptic, Dan, sodium oxalate, cellulose acetate, etc.
Low ceramic: kaolin clay, silica, clay.
Low dye categories: anthraquinone, black ferric oxide, indigo blue pigment, butyric acid, titanium hydroxide, zinc sulfide, all kinds of azo dye intermediates.
Second-ranking food: soy protein, starch gel, grains, wheat, sugar, wheat starch.
Low categories: inorganic borate, calcium carbonate, hydroxide, copper sulfate, ferric oxide, barium carbonate, antimony trioxide, all kinds of metallic hydroxide, all kinds of heavy metal salt, synthetic cryolite and so on.
Low organic matter: atrazine (pesticides), lauric acid, benzoic acid, benzoic acid, antiseptic, Dan, sodium oxalate, cellulose acetate, etc.
Low ceramic: kaolin clay, silica, clay.
Low dye categories: anthraquinone, black ferric oxide, indigo blue pigment, butyric acid, titanium hydroxide, zinc sulfide, all kinds of azo dye intermediates.
Second-ranking food: soy protein, starch gel, grains, wheat, sugar, wheat starch.
Feed system
The feed system consists of a feed vat where a discontinuous flow of product is buffered and fragmented by an agitator prior to continuous drying. A variable speed feed screw (or pump in the case of fluid feed) forwards the product to the drying chamber.
Drying chamber
The rotor at the conical base of the drying chamber fluidizes product particles in a drying-efficient hot air flow pattern in which any wet lumps are rapidly disintegrated. Hot air is supplied by a temperature-controlled air heater and speed-controlled fan, entering the drying chamber at a tangent in order to establish a turbulent, whirling air flow.
Airborne, fine particles pass through a classifier at the top of the drying chamber, while larger particles remain in the air flow for further drying and powdering.
The drying chamber is rigidly designed to withstand pressure shock in the event of explosive combustion of flammable particles. All bearings are effectively protected against dust and heat.
Bag filter
Powder from the drying chamber is collected in bag filter, while the outlet airleaves the system at the top via a suction fan.
Pneumatic coolers are a simple and reliable method of cooling and conveying dried product. In many instances ambient air will achieve the desired cooling duty. Where required, greater cooling capacity and a finer degree of control can be achieved with conditioned air at a controlled humidity and temperature.
Feature :
1. This machine combines the whirl technology with the fluidity, ejection and smashing step technologies.
2. The equipment is compact and small in size, high in production efficiency and continuous in the production. It has realized that " small equipment can perform the large production".
3. The drying capacity for this machine is big but its energy consumption is low. Its heat efficiency is high.
4. The material stay time is very short. The quality of the final products is very good. The machine can be used for drying the heat sensitive materials.
5. For the negative pressure or the micro-negative pressure operation, the machine is good for its tightness and high in the efficiency so as to eliminate the environmental pollution.
6. High drying efficiency providing low energy costs
7. Continuous processing with short processing time
8. Low operator overheads and minimum maintenance costs
9. Controlled residence time enabling high temperature drying
10. Available in cGMP compliant configurations
| spec | Barrel diameter(mm) | Main machine dimensions(mm) | Main machine power ( kw ) |
air velocity ( m3/h ) |
Water evaporation capacity ( Kg/h ) |
| XSG-2 | 200 | 250×2800 | 5-9 | 300-800 | 10-20 |
| XSG-3 | 300 | 400×3300 | 8-15 | 600-1500 | 20-50 |
| XSG-4 | 400 | 500×3500 | 10-17.5 | 1250-2500 | 25-70 |
| XSG-5 | 500 | 600×4000 | 12-24 | 1500-4000 | 30-100 |
| XSG-6 | 600 | 700×4200 | 20-29 | 2500-5000 | 40-200 |
| XSG-8 | 800 | 900×4600 | 24-35 | 3000-8000 | 60-600 |
| XSG-10 | 1000 | 1100×5000 | 40-62 | 5000-12500 | 100-1000 |
| XSG-12 | 1200 | 1300×5200 | 50-89 | 10000-20000 | 150-1300 |
| XSG-14 | 1400 | 1500×5400 | 60-105 | 14000-27000 | 200-1600 |
| XSG-16 | 1600 | 1700×6000 | 70-135 | 18700-36000 | 250-2000 |
